EGVD630ELL182MMP1H
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP POLY 1800UF 20% 63V T/H
- CategoryAluminum Electrolytic Capacitors
- Datasheet EGVD630ELL182MMP1H Datasheet
-
ECAD Model
- Share
In Stock: 383
Can ship immediately
Pricing:
- 1$5.82
- 10$5.23386
- 100$3.95409
- 500$3.25631
- 1,000$3.02371
- 2,500$2.96557
Quote It
Technical Details
- Series:GVD
- Package:Bulk
- Part Status:Active
- Capacitance:1800 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):24mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.952 A @ 120 Hz
- Ripple Current @ High Frequency:4.92 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
