381LR152M200K052
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 200V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 381LR152M200K052 Datasheet
-
ECAD Model
- Share
In Stock: 482
Can ship immediately
Pricing:
- 1$5.88
- 10$5.292
- 100$3.9984
- 500$3.2928
- 1,000$3.0576
- 2,500$3.0464
Quote It
Technical Details
- Series:381LR
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):99mOhm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3.56 A @ 120 Hz
- Ripple Current @ High Frequency:5.06 A @ 20 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):2.047" (52.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
