UWT0J221MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWT0J221MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 2,288
Can ship immediately
Pricing:
- 1$0.41
- 1,000$0.09907
- 2,000$0.09386
- 5,000$0.08864
- 10,000$0.08343
- 25,000$0.07822
- 50,000$0.073
- 100,000$0.07092
Quote It
Technical Details
- Series:UWT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:102 mA @ 120 Hz
- Ripple Current @ High Frequency:153 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.213" (5.40mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
