UMF1C470MDD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UMF1C470MDD Datasheet
-
ECAD Model
- Share
In Stock: 1,719
Can ship immediately
Pricing:
- 1$0.48
- 10$0.33257
- 100$0.19954
- 500$0.14967
- 1,000$0.12638
- 2,500$0.11973
- 5,000$0.11307
Quote It
Technical Details
- Series:UMF
- Package:Bulk
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:57.5 mA @ 120 Hz
- Ripple Current @ High Frequency:115 mA @ 100 kHz
- Impedance:1.3 Ohms
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.236" (6.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
