380LX103M063A042
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 63V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 380LX103M063A042 Datasheet
-
ECAD Model
- Share
In Stock: 2,191,822
Can ship immediately
Pricing:
- 1$6.99
- 10$6.21541
- 100$4.97233
- 500$4.2731
- 1,000$4.22648
Quote It
Technical Details
- Series:380LX
- Package:Bulk
- Part Status:Active
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):33mOhm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:6.5 A @ 120 Hz
- Ripple Current @ High Frequency:7.5 A @ 20 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
