63MXG12000MEFCSN35X45
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 12000UF 20% 63V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 63MXG12000MEFCSN35X45 Datasheet
-
ECAD Model
- Share
In Stock: 337
Can ship immediately
Pricing:
- 1$7.85
- 10$6.98099
- 100$5.58479
- 500$4.79944
- 1,000$4.45038
Quote It
Technical Details
- Series:MXG
- Package:Bulk
- Part Status:Active
- Capacitance:12000 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:4.75 A @ 120 Hz
- Ripple Current @ High Frequency:5.4625 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):1.850" (47.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
