ALA8DA301CF500
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 300UF 20% 500V SNAP
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 247
Can ship immediately
Pricing:
- 1$8.05
- 10$7.15535
- 100$5.72428
- 500$4.9193
- 1,000$4.56154
Quote It
Technical Details
- Series:ALA8D
- Package:Bulk
- Part Status:Active
- Capacitance:300 µF
- Tolerance:±20%
- Voltage - Rated:500 V
- ESR (Equivalent Series Resistance):687.4mOhm @ 100Hz
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.27 A @ 100 Hz
- Ripple Current @ High Frequency:5.2 A @ 10 kHz
- Impedance:189.4 mOhms
- Lead Spacing:-
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):2.047" (52.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
