B43505A9337M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43505A9337M000 Datasheet
-
ECAD Model
- Share
In Stock: 395
Can ship immediately
Pricing:
- 1$8.86
- 10$7.872
- 100$6.2978
- 500$5.41218
- 1,000$5.09823
Quote It
Technical Details
- Series:B43505
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):270mOhm @ 100Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.7 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:330 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):2.047" (52.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
