RV5-16V470ME55U-R2
Elna America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet RV5-16V470ME55U-R2 Datasheet
-
ECAD Model
- Share
In Stock: 5,032
Can ship immediately
Pricing:
- 1$0.37
- 1,000$0.09217
- 2,000$0.08732
- 5,000$0.08247
- 10,000$0.07762
- 25,000$0.07277
- 50,000$0.06791
- 100,000$0.06306
Quote It
Technical Details
- Series:RV5
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:52 mA @ 120 Hz
- Ripple Current @ High Frequency:67.5 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.217" (5.50mm)
- Surface Mount Land Size:0.209" L x 0.209" W (5.30mm x 5.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
