UPM1C331MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1C331MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 2,175
Can ship immediately
Pricing:
- 1$0.49
- 1,000$0.11687
- 2,000$0.11072
- 5,000$0.10457
- 10,000$0.09842
- 25,000$0.09227
- 50,000$0.08611
- 100,000$0.08365
Quote It
Technical Details
- Series:UPM
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:455 mA @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:120 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
