UUD0J330MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UUD0J330MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 2,775
Can ship immediately
Pricing:
- 1$0.49
- 1,000$0.10637
- 2,000$0.10077
- 5,000$0.09517
- 10,000$0.08958
- 25,000$0.08398
- 50,000$0.07838
- 100,000$0.07278
Quote It
Technical Details
- Series:UUD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:75 mA @ 120 Hz
- Ripple Current @ High Frequency:150 mA @ 100 kHz
- Impedance:760 mOhms
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.228" (5.80mm)
- Surface Mount Land Size:0.209" L x 0.209" W (5.30mm x 5.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
