LGN2G151MELZ35
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LGN2G151MELZ35 Datasheet
-
ECAD Model
- Share
In Stock: 402
Can ship immediately
Pricing:
- 1$4.2
- 10$3.38591
- 100$2.6406
- 500$1.96353
- 1,000$1.84164
Quote It
Technical Details
- Series:LGN
- Package:Bulk
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:850 mA @ 120 Hz
- Ripple Current @ High Frequency:1.2155 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
