B43504A2337M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 200V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43504A2337M000 Datasheet
-
ECAD Model
- Share
In Stock: 797
Can ship immediately
Pricing:
- 1$4.23
- 10$3.40919
- 100$2.65934
- 500$1.97748
- 1,000$1.84111
- 2,500$1.77292
- 5,000$1.73882
Quote It
Technical Details
- Series:B43504
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):390mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.1 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:470 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
