B43634C9277M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43634C9277M000 Datasheet
-
ECAD Model
- Share
In Stock: 465
Can ship immediately
Pricing:
- 1$5.86
- 10$5.274
- 100$3.98508
- 500$3.28186
- 1,000$3.1881
Quote It
Technical Details
- Series:B43634
- Package:Bulk
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):410mOhm @ 100Hz
- Lifetime @ Temp.:8000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.69 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:620 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
