B43501A9277M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43501A9277M000 Datasheet
-
ECAD Model
- Share
In Stock: 371
Can ship immediately
Pricing:
- 1$6.03
- 10$5.35674
- 100$4.28518
- 500$3.68262
- 1,000$3.64243
Quote It
Technical Details
- Series:B43501
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):250mOhm @ 100Hz
- Lifetime @ Temp.:10000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.62 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:400 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
