UTT1C151MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UTT1C151MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,919
Can ship immediately
Pricing:
- 1$0.88
- 1,000$0.24405
- 2,000$0.2288
- 5,000$0.21355
- 10,000$0.20592
- 25,000$0.19829
- 50,000$0.19448
Quote It
Technical Details
- Series:UTT
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:138 mA @ 120 Hz
- Ripple Current @ High Frequency:230 mA @ 100 kHz
- Impedance:680 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
