EDT687M010S9PAA
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 10V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EDT687M010S9PAA Datasheet
-
ECAD Model
- Share
In Stock: 1,557
Can ship immediately
Pricing:
- 1$0.88
- 500$0.32028
- 1,000$0.2697
- 2,500$0.25284
- 5,000$0.23599
- 12,500$0.22924
Quote It
Technical Details
- Series:EDT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:180 mA @ 120 Hz
- Ripple Current @ High Frequency:257.143 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
