UPW1H391MHD1TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1H391MHD1TO Datasheet
-
ECAD Model
- Share
In Stock: 1,495
Can ship immediately
Pricing:
- 1$0.93
- 500$0.33773
- 1,000$0.28439
- 2,500$0.26662
- 5,000$0.24884
- 12,500$0.2364
- 25,000$0.23107
Quote It
Technical Details
- Series:UPW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.11 A @ 120 Hz
- Ripple Current @ High Frequency:1.48 A @ 100 kHz
- Impedance:63 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
