UMV1E4R7MFD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4.7UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UMV1E4R7MFD Datasheet
-
ECAD Model
- Share
In Stock: 986
Can ship immediately
Pricing:
- 1$0.48
- 10$0.33829
- 100$0.22251
- 500$0.1648
- 1,000$0.14008
- 2,500$0.13184
- 5,000$0.1236
Quote It
Technical Details
- Series:UMV
- Package:Bulk
- Part Status:Active
- Capacitance:4.7 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:13 mA @ 120 Hz
- Ripple Current @ High Frequency:19.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.059" (1.50mm)
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.236" (6.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
