EKY-250ELL471MJ16S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKY-250ELL471MJ16S Datasheet
-
ECAD Model
- Share
In Stock: 884
Can ship immediately
Pricing:
- 1$0.74
- 10$0.53476
- 100$0.36246
- 500$0.27646
- 1,000$0.23959
- 2,500$0.22731
- 5,000$0.21502
Quote It
Technical Details
- Series:KY
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:605 mA @ 120 Hz
- Ripple Current @ High Frequency:1.21 A @ 100 kHz
- Impedance:60 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.630" (16.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
