UFW2A221MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UFW2A221MHD Datasheet
-
ECAD Model
- Share
In Stock: 754
Can ship immediately
Pricing:
- 1$1.09
- 10$0.85733
- 100$0.64331
- 500$0.48606
- 1,000$0.42887
- 2,500$0.40028
- 5,000$0.38599
Quote It
Technical Details
- Series:UFW
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:600 mA @ 120 Hz
- Ripple Current @ High Frequency:900 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
