UHW1C152MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHW1C152MPD Datasheet
-
ECAD Model
- Share
In Stock: 696
Can ship immediately
Pricing:
- 1$1.16
- 10$0.87879
- 100$0.62874
- 500$0.48673
- 1,000$0.41914
- 2,500$0.39209
- 5,000$0.37181
Quote It
Technical Details
- Series:UHW
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.5 A @ 120 Hz
- Ripple Current @ High Frequency:2.5 A @ 100 kHz
- Impedance:19 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
