EEU-EE2D330
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-EE2D330 Datasheet
-
ECAD Model
- Share
In Stock: 1,031
Can ship immediately
Pricing:
- 1$0.81
- 10$0.59324
- 100$0.40683
- 500$0.32211
- 1,000$0.27125
- 2,500$0.2543
- 5,000$0.23734
Quote It
Technical Details
- Series:EE
- Package:Bulk
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:322 mA @ 120 Hz
- Ripple Current @ High Frequency:920 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
