ULD2G3R3MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3.3UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ULD2G3R3MPD Datasheet
-
ECAD Model
- Share
In Stock: 703
Can ship immediately
Pricing:
- 1$0.81
- 10$0.5994
- 100$0.41125
- 500$0.32562
- 1,000$0.2742
- 2,500$0.25705
- 5,000$0.23992
Quote It
Technical Details
- Series:ULD
- Package:Bulk
- Part Status:Active
- Capacitance:3.3 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:15000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:47 mA @ 120 Hz
- Ripple Current @ High Frequency:94 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
