UHV1V471MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHV1V471MPD Datasheet
-
ECAD Model
- Share
In Stock: 623
Can ship immediately
Pricing:
- 1$0.85
- 10$0.62925
- 100$0.43147
- 500$0.34157
- 1,000$0.28763
- 2,500$0.26965
- 5,000$0.25167
Quote It
Technical Details
- Series:UHV
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:907.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.815 A @ 100 kHz
- Impedance:30 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
