EMHS101GRA111MKE0S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 110UF 20% 100V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EMHS101GRA111MKE0S Datasheet
-
ECAD Model
- Share
In Stock: 748
Can ship immediately
Pricing:
- 1$1.59
- 250$0.762
- 500$0.6477
- 750$0.6096
- 1,250$0.5715
- 2,500$0.5334
- 6,250$0.51435
- 12,500$0.48578
Quote It
Technical Details
- Series:Alchip™- MHS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:110 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):170mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:368 mA @ 120 Hz
- Ripple Current @ High Frequency:920 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.539" L x 0.512" W (13.70mm x 13.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
