UPA1C821MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPA1C821MPD Datasheet
-
ECAD Model
- Share
In Stock: 684
Can ship immediately
Pricing:
- 1$0.93
- 10$0.68544
- 100$0.46982
- 500$0.37196
- 1,000$0.31321
- 2,500$0.29364
- 5,000$0.27407
Quote It
Technical Details
- Series:UPA
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:915 mA @ 120 Hz
- Ripple Current @ High Frequency:1.22 A @ 100 kHz
- Impedance:44 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
