EEU-FC1H331L
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1H331L Datasheet
-
ECAD Model
- Share
In Stock: 452
Can ship immediately
Pricing:
- 1$0.97
- 10$0.73905
- 100$0.52888
- 500$0.40948
- 1,000$0.35261
- 2,500$0.32986
- 5,000$0.3128
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.047 A @ 120 Hz
- Ripple Current @ High Frequency:1.61 A @ 100 kHz
- Impedance:60 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
