UCZ2A820MNQ1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 82UF 20% 100V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCZ2A820MNQ1MS Datasheet
-
ECAD Model
- Share
In Stock: 356
Can ship immediately
Pricing:
- 1$1.75
- 200$0.94125
- 400$0.83667
- 600$0.71117
- 1,000$0.6275
- 2,000$0.58567
- 5,000$0.56894
Quote It
Technical Details
- Series:UCZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:82 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):280mOhm @ 100kHz
- Lifetime @ Temp.:3000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:350 mA @ 120 Hz
- Ripple Current @ High Frequency:700 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.571" (14.50mm)
- Surface Mount Land Size:0.535" L x 0.535" W (13.60mm x 13.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
