UCZ1K271MNQ1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 80V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCZ1K271MNQ1MS Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$1.84
- 125$1.0386
- 250$0.92318
- 625$0.78471
- 875$0.73856
- 1,250$0.69239
- 3,125$0.64623
- 6,250$0.62315
- 12,500$0.59787
Quote It
Technical Details
- Series:UCZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):190mOhm @ 100kHz
- Lifetime @ Temp.:3500 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:500 mA @ 120 Hz
- Ripple Current @ High Frequency:1 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
