UPT2G270MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 27UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPT2G270MHD Datasheet
-
ECAD Model
- Share
In Stock: 968
Can ship immediately
Pricing:
- 1$1.33
- 10$1.05359
- 100$0.7906
- 500$0.5973
- 1,000$0.52703
- 2,500$0.49189
- 5,000$0.47433
Quote It
Technical Details
- Series:UPT
- Package:Bulk
- Part Status:Active
- Capacitance:27 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:240 mA @ 120 Hz
- Ripple Current @ High Frequency:384 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
