UHE1A472MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1A472MHD Datasheet
-
ECAD Model
- Share
In Stock: 828
Can ship immediately
Pricing:
- 1$1.35
- 10$1.06865
- 100$0.80117
- 500$0.60533
- 1,000$0.53411
- 2,500$0.49851
- 5,000$0.4807
Quote It
Technical Details
- Series:UHE
- Package:Bulk
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.304 A @ 120 Hz
- Ripple Current @ High Frequency:2.88 A @ 100 kHz
- Impedance:20 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.398" (35.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
