UVZ0J103MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVZ0J103MHD Datasheet
-
ECAD Model
- Share
In Stock: 519
Can ship immediately
Pricing:
- 1$1.39
- 10$1.10051
- 100$0.82504
- 500$0.62337
- 1,000$0.55002
- 2,500$0.51336
- 5,000$0.49869
Quote It
Technical Details
- Series:UVZ
- Package:Bulk
- Part Status:Active
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.65 A @ 120 Hz
- Ripple Current @ High Frequency:1.8975 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
