EEU-EB2D680S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-EB2D680S Datasheet
-
ECAD Model
- Share
In Stock: 475
Can ship immediately
Pricing:
- 1$1.49
- 10$1.17252
- 100$0.87944
- 500$0.66443
- 1,000$0.58626
- 2,500$0.54717
- 5,000$0.52763
Quote It
Technical Details
- Series:EB
- Package:Bulk
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:412.5 mA @ 120 Hz
- Ripple Current @ High Frequency:750 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
