ELXY250ELL102MK25S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXY250ELL102MK25S Datasheet
-
ECAD Model
- Share
In Stock: 355
Can ship immediately
Pricing:
- 1$1.53
- 10$1.161
- 100$0.8301
- 500$0.6426
- 1,000$0.55335
- 2,500$0.51765
- 5,000$0.49088
Quote It
Technical Details
- Series:LXY
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.014 A @ 120 Hz
- Ripple Current @ High Frequency:1.69 A @ 100 kHz
- Impedance:34 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
