EEV-TG1K101M
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 80V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEV-TG1K101M Datasheet
-
ECAD Model
- Share
In Stock: 319
Can ship immediately
Pricing:
- 1$2.49
- 125$1.4709
- 250$1.26078
- 625$1.12068
- 875$1.05063
- 1,250$0.98059
- 3,125$0.94557
- 6,250$0.91054
Quote It
Technical Details
- Series:TG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):300mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:227.5 mA @ 120 Hz
- Ripple Current @ High Frequency:350 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
