228CKH035M
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 35V T/H
- CategoryAluminum Electrolytic Capacitors
- Datasheet 228CKH035M Datasheet
-
ECAD Model
- Share
In Stock: 7,801,684
Can ship immediately
Pricing:
- 1$1.62
- 10$1.27532
- 100$0.95649
- 500$0.72268
- 1,000$0.63766
- 2,500$0.59515
- 5,000$0.5739
Quote It
Technical Details
- Series:CKH
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):121mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.73 A @ 120 Hz
- Ripple Current @ High Frequency:2.422 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
