EEE-FK1V162SM
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1600UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-FK1V162SM Datasheet
-
ECAD Model
- Share
In Stock: 714
Can ship immediately
Pricing:
- 1$2.63
- 125$1.55036
- 250$1.32886
- 625$1.18122
- 875$1.10739
- 1,250$1.03357
- 3,125$0.99666
- 6,250$0.95974
Quote It
Technical Details
- Series:FKS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1600 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.35 A @ 120 Hz
- Ripple Current @ High Frequency:1.8 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
