EEE-TKV681UAM
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-TKV681UAM Datasheet
-
ECAD Model
- Share
In Stock: 462
Can ship immediately
Pricing:
- 1$2.78
- 125$1.64125
- 250$1.40676
- 625$1.25048
- 875$1.17231
- 1,250$1.09417
- 3,125$1.05508
- 6,250$1.01601
Quote It
Technical Details
- Series:TK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):80mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:825 mA @ 120 Hz
- Ripple Current @ High Frequency:1.1 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
