UPJ1K391MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 80V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1K391MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 580
Can ship immediately
Pricing:
- 1$1.73
- 10$1.36901
- 100$1.02716
- 500$0.77604
- 1,000$0.68473
- 2,500$0.63908
- 5,000$0.62083
Quote It
Technical Details
- Series:UPJ
- Package:Bulk
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:908 mA @ 120 Hz
- Ripple Current @ High Frequency:1.17 A @ 10 kHz
- Impedance:89 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
