UPT2D151MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPT2D151MHD Datasheet
-
ECAD Model
- Share
In Stock: 369
Can ship immediately
Pricing:
- 1$2.17
- 10$1.70825
- 100$1.28144
- 500$0.96814
- 1,000$0.85425
- 2,500$0.7973
- 5,000$0.76883
Quote It
Technical Details
- Series:UPT
- Package:Bulk
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:620 mA @ 120 Hz
- Ripple Current @ High Frequency:992 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
