UVY0J153MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15000UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVY0J153MHD Datasheet
-
ECAD Model
- Share
In Stock: 448
Can ship immediately
Pricing:
- 1$2.18
- 10$1.76707
- 100$1.34964
- 500$1.02831
- 1,000$0.89977
- 2,500$0.86764
- 5,000$0.83551
Quote It
Technical Details
- Series:UVY
- Package:Bulk
- Part Status:Active
- Capacitance:15000 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.82 A @ 120 Hz
- Ripple Current @ High Frequency:2.093 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.319" (33.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
