EEU-FC1C682
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1C682 Datasheet
-
ECAD Model
- Share
In Stock: 327
Can ship immediately
Pricing:
- 1$2.34
- 10$1.89506
- 100$1.44734
- 500$1.10272
- 1,000$0.96488
- 2,500$0.93042
- 5,000$0.89597
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.856 A @ 120 Hz
- Ripple Current @ High Frequency:3.36 A @ 100 kHz
- Impedance:15 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.575" (40.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
