UHW1K681MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- Description80V 681UF 20% HIGH RELIA-LEADED
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHW1K681MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 284
Can ship immediately
Pricing:
- 1$2.44
- 10$1.97739
- 100$1.5096
- 500$1.15018
- 1,000$1.00641
- 2,500$0.97046
- 5,000$0.93452
Quote It
Technical Details
- Series:UHW
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.458 A @ 120 Hz
- Ripple Current @ High Frequency:2.43 A @ 100 kHz
- Impedance:40 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
