ELXY250ELL272ML30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2700UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXY250ELL272ML30S Datasheet
-
ECAD Model
- Share
In Stock: 475
Can ship immediately
Pricing:
- 1$2.51
- 10$2.0036
- 100$1.54122
- 500$1.20215
- 1,000$1.07886
- 2,500$1.01721
- 5,000$0.98639
Quote It
Technical Details
- Series:LXY
- Package:Bulk
- Part Status:Active
- Capacitance:2700 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.7625 A @ 120 Hz
- Ripple Current @ High Frequency:2.35 A @ 100 kHz
- Impedance:25 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
