ESMG350ELL222ML25S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ESMG350ELL222ML25S Datasheet
-
ECAD Model
- Share
In Stock: 798
Can ship immediately
Pricing:
- 1$2.8
- 10$2.20854
- 100$1.65641
- 500$1.25151
- 1,000$1.10427
- 2,500$1.03065
- 5,000$0.99384
Quote It
Technical Details
- Series:SMG
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.785 A @ 120 Hz
- Ripple Current @ High Frequency:1.9278 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
