EEU-FC1A122B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1A122B Datasheet
-
ECAD Model
- Share
In Stock: 1,176
Can ship immediately
Pricing:
- 1$0.78
- 500$0.28478
- 1,000$0.23982
- 2,500$0.22483
- 5,000$0.20984
- 12,500$0.19935
- 25,000$0.19485
- 50,000$0.19111
Quote It
Technical Details
- Series:FC
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:976 mA @ 120 Hz
- Ripple Current @ High Frequency:1.22 A @ 100 kHz
- Impedance:52 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
