UUL1V221MNL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UUL1V221MNL1GS Datasheet
-
ECAD Model
- Share
In Stock: 893
Can ship immediately
Pricing:
- 1$0.98
- 500$0.35822
- 1,000$0.30847
- 2,500$0.28857
- 5,000$0.27364
- 12,500$0.25931
- 25,000$0.25777
Quote It
Technical Details
- Series:UUL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:216 mA @ 120 Hz
- Ripple Current @ High Frequency:324 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
