ULT2H3R3MNL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3.3UF 20% 500V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet ULT2H3R3MNL1GS Datasheet
-
ECAD Model
- Share
In Stock: 945
Can ship immediately
Pricing:
- 1$1
- 500$0.38175
- 1,000$0.32873
- 2,500$0.30752
- 5,000$0.29161
- 12,500$0.28844
Quote It
Technical Details
- Series:ULT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:3.3 µF
- Tolerance:±20%
- Voltage - Rated:500 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:35 mA @ 120 Hz
- Ripple Current @ High Frequency:52.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
