UPA0J272MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2700UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPA0J272MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,150
Can ship immediately
Pricing:
- 1$1.21
- 500$0.42272
- 1,000$0.36401
- 2,500$0.34053
- 5,000$0.32291
- 12,500$0.306
- 25,000$0.29943
Quote It
Technical Details
- Series:UPA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:2700 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.428 A @ 120 Hz
- Ripple Current @ High Frequency:1.68 A @ 100 kHz
- Impedance:33 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
